Aluminium Flat LED Strips Corner Profile

Get a Price/Quote

Aluminium Flat LED Strips Corner Profile Specification

Features
Easy installation, lightweight, durable, heat dissipation, aesthetic design

Size
2 meters (customizable length)

Thickness
1.2mm

Usage & Applications
LED strip corner mounting, architectural lighting, display lighting, under cabinet lighting

Cross Dimension
16mm x 16mm

Corrosion Resistant
Yes

Finish
Satin / Matte / Anodized

Width
16mm

Material Grade
Aluminium 6063

Material
Aluminium

Fabrication Process
Extruded

Length
2 meters

Temper
T5

Product Type
Aluminium LED Corner Profile

Shape
Triangular / Corner

Strength
High

Hardness
Medium

Alloy
6063

Grade
6063-T5

Surface Treatment
Anodized

Dimension (L*W*H)
2000mm x 16mm x 16mm

Color
Silver / White / Black

Cuttable
Yes

Packing
Individually packed in protective sleeve

Included Accessories
End caps, mounting clips

Protection Level
IP20 (non-waterproof)

Fire Rating
UL94 V-0 rated diffuser

Operating Temperature Range
-20°C to +60°C

Weight
Approx. 0.18 kg/meter

Compatible Strip Width
Up to 10mm

Mounting Type
Surface Mount

Diffuser Type
Frosted PC / Clear Polycarbonate

About Aluminium Flat LED Strips Corner Profile

We provide a wide range of Aluminium Flat LED Strips Corner Profile to our valuable clients. Offered profile is a perfect enclosure for electrical components. This profile is mainly used for covering LED strips in a hassle-free manner. Offered profile is tested on different parameters for ensuring flawless delivery to clients. Provided profile finds its usefulness in commercial, residential and industrial places. Apart from this, offered Aluminium Flat LED Strips Corner Profile is known for its heat-resistant nature.

Key Points:

User-friendly design
Optimum strength
Perfect finish

Engineered for Versatile, Stylish Lighting

This aluminium corner profile delivers superior lighting for a range of indoor applications, from under-cabinet to architectural accents. Its triangular cross-section fits seamlessly into corners, while the anodized finish ensures both aesthetic appeal and enhanced surface durability. Compatible with standard 10mm LED strips, the profiles advanced design provides effective heat dissipation, optimizing LED lifespan.

Easy, Secure Installation and Customization

Supplied with mounting clips, end caps, and individually packed for protection, the profile is tailored for user-friendly installation. Its surface-mount design allows for straightforward assembly in various settings. Customizable lengths and multiple color options support diverse design requirements, providing flexibility for projects both large and small.

Safety, Durability & Performance Combined

Crafted from premium Aluminium 6063-T5, the profile offers high mechanical strength, medium hardness, and excellent corrosion resistance. The diffuser, available in frosted or clear polycarbonate, is UL94 V-0 fire rated for enhanced safety. Designed for dry indoor environments (IP20), this profile is a dependable solution for demanding lighting needs.

FAQs of Aluminium Flat LED Strips Corner Profile:

Q: How do I install the Aluminium Flat LED Strips Corner Profile?

A: Installation is straightforward: secure the profile using the included mounting clips at your desired corner location, insert your LED strip (up to 10mm width) into the channel, position the diffuser (frosted or clear), and finish by attaching the end caps for a clean, professional look. No specialized tools are required.

Q: What types of LED strips are compatible with this corner profile?

A: The profile accommodates LED strips up to 10mm in width, making it suitable for most standard single or multi-color LED tapes. Its particularly designed for architectural, under-cabinet, and display lighting applications where corner mounting is required.

Q: When should I choose a frosted diffuser versus a clear diffuser?

A: Select a frosted diffuser when you desire a softer, more even light distribution and wish to minimize visible LED dots. Opt for the clear polycarbonate diffuser if you prefer maximum brightness and a more direct lighting effect. Both offer UL94 V-0 fire safety ratings.

Q: Where can this aluminium profile be used?

A: This surface-mount corner profile is ideal for indoor applications such as under-cabinet lighting, display case illumination, cove lighting, and architectural highlights in homes, offices, or retail environments. It should not be used in wet areas, as it is IP20 rated (non-waterproof).

Q: What are the benefits of using an anodized aluminium corner profile for LED strips?

A: The anodized aluminium construction ensures excellent heat dissipation, extending the life of your LEDs. It also provides a robust, corrosion-resistant finish that enhances durability, ease of cleaning, and maintains a sleek, modern appearance in any setting.

Q: How can I customize the length of the profile for my project?

A: Each profile comes in a standard 2-meter length and can be cut to custom sizes using standard metal cutting tools, allowing precise fitting for your specific project needs.
